建伍DVD 建伍Kenwood Keyty方向盘按键适配器 德国Goldbor
  • 型号: San Franciso 320  产品对比
  • 规格: 1-DIN USB/MP3主机
  • 售价: RMB¥1499 元


官方页面:http://www.blaupunkt.de/index.php?id=938&tx_ddfproducts2_pi1[view]=1908

英文版说明书下载:http://www.chenxiaowei.com/manual/320en.pdf


旧金山 320(San Francisco 320)


BLAUPUNKT
San Francisco 320

Becoming a DJ is as simple as listen to the music.

Key Functions:
Ausstattung Data carrier
CD-DA, CD-R, CD-RW
USB
SDHC, SD, MMC
Media player
Twin-encoder concept for fast & comfortable MP3 folder/file browsing and iPod criteria/track search
Various display modes (ID3-tags, play time, …, all Info)
Fast reading of USB/SDHC/SD/MMC media
Playback formats: MP3, WMA
Radio
FM, AM (MW, LW) tuner
Equalizer
Number of bands: 3
Model: Semi-parametric
Amplifier
Max. power: 4 x 50 W
Sinus power at 14,4 V: 4 x 22 W
Display
15 digits plus intuitive status icons
Inputs
2 x USB, front & rear, mass storage device (MSD)
iPod / iPhone direct control via USB
SDHC/SD/MMC card slot (behind release panel)
Front Aux-in
Audio mix (music & navigation)
Outputs
Pre-amplifier 4-channel (2 V)
Sub-out (variable gain/frequency)
Panel
Detachable
General
Software update via USB



More Technical Details:
Data carrier
CD: CD-DA, CD-R, CD-RW
Type disk-drive: automatic loading
USB-removable storage: USB 2.0
Memory cards: SDHC, SD, MMC
Formatting USB: FAT 32, FAT 16
Formatting memory card: FAT 32, FAT 16
Media player
Playback format: MP3, WMA
Title display: ID3-tag (version 2), file, folder
MP3 folder & file browsing: Yes (LIST-key / w/o playback interruption)
MP3 file search: Yes (by name / long press LIST-key)
iPod criteria browsing: Yes (ID3-key / by artists, albums, genres, playlists, audiobooks)
Fast list browsing: Yes (via browsing encoder)
Short cut iPod playlists: Yes (long press ID3-key)
Display modes: Yes (file, artist, album, genre (iPod), song, elapsed time, total time, all)
Display of characters: up to 32
Variable display scrolling: Yes (once / always if > 15 digits)
Fast media reading: Yes (from USB/SDHC/SD/MMC)
Mix / Repeat / Scan: Yes / Yes / Yes
Bitrate (kBit/s): 32 – 320
Variable bitrates: Yes
CD player
Shock proof memory: Yes
Frequency response (Hz) -1 dB: 20 – 20.000
Radio
Type of tuner: Codem receiver
Tuner areas: World tuner, switchable via menu (EU/USA/SouthAmerica/Thailand)
Wave bands: FM, AM (MW, LW)
Radio Data System (RDS): Programme Service Name (PS), Alternative Frequency (AF), Regional Programme (REG), Enhanced Other Networks (EON), Program Types (PTY), Traffic Program (TP), Traffic Announcement (TA), Clock Time (CT)
Travelstore: Yes
Station memory: 25
Band Scan / Preset Scan: Yes / Yes
Interference suppression: Yes
Frequency response (Hz) -3 dB: 30 – 15.000
Equalizer
Number of bands: 3
Model: semi-parametric
Type: analogue
X-Bass: Yes
Sound presets: pop, rock, classic
Amplifier
Number of channels: 4
Max. power (Watt): 4 x 50
Sinus power at 14.4 V (Watt): 4 x 22
Display
Type: DOT (1-line)
Digits: 15
Colour: negative black and white
Brightness: adjustable
Clock display: 24 / 12 hrs
Inputs
Antenna (number of): 1 (ISO)
USB (number of, type): 2 (front + rear / standard A-type)
USB (features): mass storage device (MSD)
iPod/iPhone: direct control via USB
Memory cards: SDHC/SD/MMC (behind panel)
Aux-In (number of, type): 1 front (3.5 mm jack)
Aux-In (features): variable gain / Aux naming
Audio mix (music & navigation): Yes
Telephone mute: Yes
Telephone Line-In: Yes (rear)
Remote control (RC10): Yes (via front IR-eye and via ISO)
Outputs
Loud speaker (number of): 4
Pre-amplifier: 4-Channel (2 V), cinch
Variable amplifier delay time: Yes
Sub-out: Yes (variable gain/frequency)
General
Twin-encoder concept: Left for volume control & mute, Right exclusively for browsing, tuner search & user menu
Software update: Yes (via USB)
Variable scan time: Yes (4/8/12/16/60 seconds)
Confirmation beep: Yes (on/off)
Front panel: detachable
Panel color: black, dark chrome
Encoder / key illumination: blue / red
Permanent storage after car battery disconnect: Yes
Demo mode: Yes
Demo mode activation: via user menu
Installation location: 1-DIN-slot
Weight (kg): ca. 1.70
Height x Width x Depth (mm): 50 x 178 x 160
Accessories included in delivery
Europe variant
Order number: 1 011 202 320 001
Case for front panel: Yes
Instruction book: Yes (16 languages)
Mounting material: Yes
Antenna adapter: Yes
World variant
Order number: 1 011 202 321 001
Case for front panel: Yes
IR remote control: Yes
Instruction book: Yes (6 languages)
Connector cable power supply: Yes (ISO chamber A)
Connector cable Sub-out: Yes (ISO chamber A, cinch)
Connector cable speakers: Yes (ISO chamber B)
Mounting material: Yes
Antenna adapter: Yes
Subject to technical modification. iPod and iPhone are registered trademarks of Apple Computer, Inc.


中文翻译:

德国蓝宝 型号:旧金山 320(San Francisco 320),这款机超经典古典设计,有点像烧鸡麦景图。

成为一个DJ,就像听音乐那么简单!

简要功能:
1、支持CD-DA,CD-R,CD-RW光盘格式
2、USB/SDHC卡/SD卡/MMC卡,快速双解码概念设计,支持MP3(目录/文件形式),iPod(标准/歌曲形式)顺序浏览和搜索
3、快速读取USB/SDHC卡/SD卡/MMC卡文件,可选播放显示模式(歌曲ID3信息,播放时间,以及所有歌曲信息)
4、支持格式:MP3,WMA
5、收音支持FM,AM(MW,LW)
6、EQ均衡,预设置3段均衡
7、内置最大4X50W功放,实际输出功率4X22W有效值,当14.4伏特电压时
8、显示屏:高精度15位字符显示,直观图标
9、接口:前/后2个USB口,SDHC/SD/MMC卡槽(位于面板后面),USB直接支持iPod/iPhone,前置AUX(支持音乐和导航混响)
10、前级输出:4声道(2伏电平),单独一路低音输出,也就是三路输出。
11、面板可拆卸
12、可断电记忆设置(电池断开连接)
13、支持USB软件升级
14、配原厂遥控器

关于尺寸:国际标准1DIN位
主机裸重:1.7公斤
厚x宽x深: 50 x 178 x 170 (毫米)


详细参数描述,这里就不翻译了,自己可以贴过去谷歌翻译。
